Allen Bradley 1756-IR6I

1756-IR6I Allen Bradley  Rockwell AutomationKey Features:Isolated RTD Compatibility: Supports multiple RTD types, including Platinum with alpha=385 and alpha=3916, and Nickel with alpha=672 and alpha=618. High-Resolution Measurement: Offers 16-bit resolution for precise temperature readings across different input ranges. Fast Scan Times: Ensures quick response with a module scan time as low as 10 ms in integer mode. Data Format Flexibility: Provides data in both integer mode and IEEE 32-bit floating point format.Technical Specifications:Series: ControlLogix Inputs: 6-Point Isolated RTD Module Type: Analog RTD Module Resolution: 16 bits, varying by range Input Range: 1–487, 2–1000, 4–2000, 8–4000 ohms Module Scan Time: As fast as 10 ms in integer mode Maximum Input Current (Off-State): 2.75 milliamperes Backplane Current: 250 milliamps at 5 Volts, 2 milliamperes at 24 Volts Power Dissipation (Max): 4.3 Watts Removable Terminal Blocks: 1756-TBNH, 1756-TBSH UPC: 10612598172303 Applications: Perfect for applications requiring high-precision temperature monitoring, the 1756-IR6I is ideal for use in process control, quality assurance in manufacturing, and environmental monitoring systems.Why Choose the 1756-IR6I?Select the Allen-Bradley 1756-IR6I for its exceptional versatility in RTD compatibility, high-resolution measurements, and rapid module scan times. This module is designed to enhance the accuracy and reliability of your industrial temperature sensing applications.Additional Information:This module operates within a maximum current of 1.2 milliamperes at 30 Volts AC, 60 Hertz, ensuring energy-efficient performance. With its robust design and compatibility with various RTD types, the 1756-IR6I is a valuable addition to your ControlLogix system.DocumentationRESOURCE PUBLICATION NUMBER Technical Data 1756-td002_-en-e
