1756-ON8 Allen Bradley

1756-ON8 Allen Bradley Rockwell AutomationKey Features:8-Point Output Capability: The 1756-ON8 offers eight robust output points, making it ideal for a variety of control applications.Wide Voltage Range: Operates on a voltage range of 10-30 Volts AC, making it compatible with different power sources and ensuring flexibility in various industrial settings.High Output Current Rating: Each point can handle up to 2 Amps at 60 degrees Celsius, while the module can manage a maximum of 5 Amps at 30 degrees Celsius and 4 Amps at 60 degrees Celsius.Technical Highlights:Manufacturer: Rockwell AutomationBrand: Allen-BradleyPart Number: 1756-ON8Series: ControlLogixModule Type: Output ModuleOutputs: 8-PointVoltage: 240 Volts ACOperating Voltage Range: 10-30 Volts ACMaximum Output Current Rating-Point: 2 Amps at 60 degrees CelsiusMaximum Output Current Rating-Module: 5 Amps at 30 degrees Celsius, 4 Amps at 60 degrees CelsiusPower Dissipation (Max): 5.1 Watts at 60 degrees CelsiusBackplane Current at 5 Volts: 200 milliampsRemoveable Terminal Block(s): 1756-TBNH, 1756-TBSHIsolation Voltage: 50 Volts ContinuousUPC: 10612598171450Why Choose the 1756-ON8?Versatile Functionality: Utilize the 1756-ON8 in a network of producer and consumer models to generate information on demand and enhance system functionality.Efficient Power Management: With a total backplane power of 1.07 W and maximum power dissipation of 5.1 W at 60 °C, this module is designed for energy efficiency.Durable Construction: Built to withstand the demands of industrial environments, the 1756-ON8 operates within a temperature range of 0-60 °C and is resistant to shocks and vibrations.DocumentationRESOURCEPUBLICATION NUMBERTechnical Data1756-TD002
