1756-OF8H Allen Bradley

1756-OF8H Allen Bradley Rockwell AutomationTechnical specifications for 1756-OF8HManufacturerRockwell AutomationBrandAllen-BradleyPart Number/Catalog No.1756-OF8HManufacturerRockwell AutomationSeriesControlLogixBrandAllen-BradleyModule TypeHart Analog Output ModuleSeriesControlLogixOutputs8 DifferentialModule TypeAnalog output Module with HART capabilityInput Current Range0-20 or 4-20 milliampsNo. of InputsEight (8) output channelsIsolation Voltage50 Volts ContinuousOutput signalCurrent: 0-20 mA; 4-20 mA Voltage: /-10VDCOvervoltage Protection24 Volts DCResolution15-16 BitsEnclosureOpenAccuracyVoltage: 0.1% of range Current: 0.5% of rangeRemoveable Terminal Blocks1756-TBNH, 1756-TBSHData Format:Integer mode (left justified, 2 s complement) IEEE 32-bit floating pointInput conversion methodSuccessive approximationOutput conversion methodR-Ladder DAC, monotonicity with no missing codesRemoveable Terminal Block(s)1756-TBNH, 1756-TBSHRemovable terminal block1756-TBCH; 1756-TBSHCurrent Draw230 mA @ 5.1 VDC and 230 mA @ 24 VDCEnclosureNoneOpen circuit detection timeCurrent output only (output must be set to < 0.1 mA)UPC10612598345486Overvoltage protection, max /- 24 VDCDescriptionThe Allen-Bradley 1756-OF8H is an analog output module from the ControlLogix controller platform. This module mainly features Eight (8) voltage or current output channels, configurable for 0-20 mA and 4-20 mA current output signals and /-10VDC voltage output signals. The 1756-OF8H has a module resolution of 15-16bits on all signal ranges. It comes with internal Digital to Analog converter (DAC) using R-Ladder DAC, monotonicity with no missing codes conversion method with data format of Integer mode (left justified, 2 s complement) IEEE 32-bit floating-point. This module is installed to a 1756 ControlLogix chassis and occupies a single slot only. It can function as a local IO module and remote I/O module component. For the termination of signal wires, this module comes with a removable terminal block (RTB). This RTB can be replaced with 1756-TBNH or 1756-TBSH with user-defined mechanical RTB keying. Applicable wire size when 1756-TBNH is used is 0.33-2.1 mm2 (22-14 AWG) for single-wire connection and 0.33…1.3 mm2 (22…16 AWG) for double wire connection. 1756-TBSH supports single wire connection only and is designed for wire 0.33…1.3 mm2 (22…16 AWG) wire size. The 1756-OF8H has a continuous isolation voltage rating of 50V. Module isolation is between output channels to backplane only. Each output channel does not come with individual isolation. Additionally, the module’s open circuit detection time is available for current configuration only while the maximum overvoltage protection is /- 24 VDC.The 1756-OF8H ControlLogix Voltage/Current Analog Output Module by Allen-Bradley is an analog output module that has 8 voltage or current outputs with a single HART modem per module. It has a selectable voltage/current signal range of -10.4336-10.4336V and 0-21.2916mA. The 1756-OF8H has an overall output rating of /- 10V or 0-20mA and a signal resolution of 15-16 bits for all ranges. It also has a backplane current draw of 230 mA @ 5.1 VDC and 230 mA @ 24 VDC, total backplane power of 6.54W. It has a thermal dissipation of 16.78 BTU/hr, and a power dissipation of 4.92W. The 1756-OF8H has an isolation voltage of 50V with basic insulation tested at 1500V AC for 60s between output channels and the backplane. The 1756-OF8H, unlike other Analog I/O modules, offers Open Circuit Detection and has a circuit detection time at a value that must be set below 0.1 mA. Its current settling time without HART is just below 23ms, and below 37ms with HART and its voltage settling time is 8.5ms to 95% with resistive loads. It has a calibration accuracy (without HART) of 0.1% (voltage) and 0.15% (current) and its standard calibration interval is about 12 months. The 1756-OF8H has an offset drift of 100 V/deg C. or 200nA/deg. C and the module has an overall module error of 0.15% (voltage) or 0.3% (current). It has a T4 North America, ATEX, and IEC temperature code, and has an open-style enclosure rating. The 1756-OF8H’s operational temperature ranges between 0 deg. C and 60 deg. C at 5-95% non-condensing relative humidity.RevisionsRevision Part #Also known as1756-OF8H Ser A1756-OF8H/A, Series A, Rev AAlternative names1756-0F8H1756-OFBH17560F8H1756OF8H1756OFBHL756-0FBHL756-OF8HL7560FBHL756OF8HFrequently asked questionsWhat is the conversion resolution of the 1756-OF8H?The 1756-OF8H has 15-16 bit resolution.What are compatible Removable Terminal Block (RTB) for use with this module?Compatible RTB module are 1756-TBNH and 1756-TBSH.Does the 1756-OF8H support HART protocol?Yes. HART protocol is supported by the 1756-OF8H.Technical notesAllen Bradley ControlLogix Hart Analog Output Module with 8 Differential OutputsDocumentationRESOURCEPUBLICATION NUMBERTechnical Data1756-TD002
